| Printing Method |
|
| Printing Technology |
4-color thermal inkjet |
| Maximum Resolution |
1200 x 1200 input dpi |
| Line Accuracy |
±0.1% |
| Ink Palette |
Cyan, Magenta, Yellow, Black |
| Ink Type |
Dye-Based: Cyan, Magenta, Yellow
Pigment-Based: Black |
| Ink Cartridge Configuration |
4 individual cartridges |
| Maximum Optical Density |
2.10 maximum black optical density (8 L*min) |
| Printer Language |
HP-GL/2, HP-RTL, HP PCL 3 GUI, JPEG, CALS G4 |
| Print Speed |
US D – Best: 16.3 min/page
US D – Normal: 9.3 min/page
US D – Draft: 1.3 min/page |
| Paper Handling |
|
| Paper-Feed Method |
Sheet feed, roll feed, input tray; |
| Cutter |
Automatic cutter |
| Maximum Paper Width |
24.0″ (60.96 cm) |
| Paper Sizes |
Sheet: 8.3 x 11.0 to 24.0 x 66.0″ (21.0 x 27.94 to 60.96 x 167.6 cm)
Roll Width: 11.0 to 24.0″ (27.94 to 60.96 cm) |
| Paper Types |
Plain: Bond, coated, heavyweight coated, recycled, plain, bright white
Technical: Natural tracing, vellum
Film: Clear, matte
Photo: Satin, gloss, semigloss, premium, polypropylene
Self-Adhesive: Adhesive, polypropylene |
| Media Thickness |
Up to 11.8 mil (299.72 micron) |
| Media Weight |
Roll Feed: 60 to 280 g/m2
Manual Feed: 60 to 280 g/m2
Input Tray: 60 to 220 g/m2 |
| Maximum Roll Print Length |
150.0′ (46.0 m) |
| Maximum Media Roll Diameter |
3.9″ (9.91 cm) |
| Connectivity |
|
| Interface |
Hi-Speed USB 2.0
Fast Ethernet (100Base-T)
Wi-Fi |
| OS Compatibility |
Windows: Windows 7 Ultimate/Professional/Home Premium, Vista Ultimate/Business/Home Premium, XP (32/64-bit) Professional/Home, Server 2008 (32/64-bit), Server 2008 R2, Server 2003 (32/64-bit)
Mac: OS X 10.6, 10.7, 10.8
Citrix: XenApp, XenServer |
| Internal Memory |
1.0 GB |
| Physical |
|
| Control Panel |
LCD: 4.3″ color touchscreen
Icons: Wireless, Home, Help, Previous/Next, Back, Cancel |
| Power Requirements |
100 to 240 V AC ±10%, 50/60 Hz, 1200 mA max |
| Power Consumption |
Printing: < 35 W
Power Save: < 4.5 W
Standby: < 0.3 W |
| Acoustic Noise |
Sound Power (Operating): 6.5 B(A)
Sound Power (Standby): < 3.4 B(A)
Sound Pressure (Operating): 48 dB(A)
Sound Pressure (Standby:) < 16 dB(A) |
| Certifications |
Safety: CSA, EU (LVD and EN 60950-1 compliant), Russia (GOST), Singapore (PSB), China (CCC), Mexico (NYCE)
Electromagnetic: Class B requirements, including USA (FCC rules), Canada (ICES), EU (EMC/R&TTE Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Certified as Class A product: Korea (KCC)
Environmental: Energy Star, WEEE, EU RoHS, REACH, EuP, FEMP |
| Temperature / Humidity |
Operating Temperature: 41 to 104 °F (5 to 40 °C)
Recommended: 59 to 95 °F (15 to 35 °C)
Storage Temperature: -13 to 131 °F (-25 to 55 °C)
Operating Humidity: 20 to 80%
Storage Humidity: 0 to 95% |
| Dimensions |
38.9 x 20.9 x 11.2″ (98.81 x 53.09 x 28.45 cm) |
| Weight |
56.2 lb (25.49 kg) |
